Pump House Heaters
PHT500 UTILITY & WELL HOUSE HEATER
• 500 Watt Output
• Enclosed Element
• Rugged Construction
• Built-In Freeze Protection Thermostat
• Dual Voltage Rating
• Neutral Grey Finish
UL listed - FILE #E21609
APPLICATIONS:
With Berko’s Electric Utility Heater, You Can Quit Worrying About Costly Troublesome Freeze-Ups. Install It Anywhere Heat Is Needed To Prevent Pipes, Pumps, and Other Water, Hydraulic Fluid or Oil-Filled Equipment From Freezing. You’ll Find The PHT500 Ideal To Heat Any Small Confined Area Such As Suburban and Farm Home Pump Houses, Well Pits, Ski Lift Booths, Relay Stations, Construction Sheds, Toll Booths, Ticket Booths and As an Oil Preheater In Boiler Rooms. It Is Always On Guard When You Can’t Be.
It Is Designed To Provide Automatic, 24-Hour Protection. Set The Thermostat at Any Desired Level and Leave It. There Are No Moving Parts. It Is Maintenance Free, and Can Be Left Unattended All Winter Long — Ideal For Remote Locations. The Built-In Quick Response Thermal Cutout Protects Against Overheating.

FEATURES
STURDY CONSTRUCTION:
The Heater Is Housed
In an Epoxy Painted Galvanized Steel Case For Corrosion
Protection. All Power Supply and Control Wiring
Terminates In The Tamperproof Control Box —
No Live Voltage In The Element Area.

STEEL SHEATH:
Aluminum Fin Element — This
Type Element Provides Fast Heat Dissipation and Long
Life Because of Cooler Sheath Temperatures.

DUAL VOLTAGE:
The PHT500 Is Shipped From The
Factory Wired For 240/208V Operation. It Is Field
Adaptable For Use On 120V Supply.


BUILT-IN THERMOSTAT
The Durable Thermostat
Is Completely Contained Within The Control Box.
Temperature Control Range Is 40° to 70°F.

EASY TO INSTALL:
The PHT500 Is Designed For Fast, Easy Installation In Hard To Reach Places. Screw Holes Are Provided at Each End of The Unit. The Control Box Has a Pre-Punched Service Entrance at The End For 1/2” Conduit or Non-Metallic Sheathed Cable Fittings, and Is Prewired
For Easy Field Connections A Positive Ground Clip Is Also Provided.

SELECTION CHART
CATALOG
NUMBER

VOLTS
WATTS
THERMOSTAT TEMP. RANGE
AMPS

SHIP WT. (lbs.)

Price

Add To Cart
PHT-500
120
*240/208
500
500/376
40-70°F
4.2
2.1/1.8
6
118.97
*As Shipped. Can Be Field Rewired For 120V.


We've seen your application. Call Us for application Assistance

(901) 452-4516
