CEILING FANS
HEAVY DUTY COMMERCIAL CEILING FANS	Instruction Manual	Bulletin
You MUST have Adobe Acrobat Reader to view any literature downloaded from this website.

UL 507 states Ceiling Fans suspended from 7 feet to less than 10 feet (blade height to floor) must have minimum thickness of edge of blade 3/16” U.S. PATENT# 5,645,403
Provides Superior Air Velocity and Efficiency, The Ideal School Classroom Fans (Models 48" and 56"). Suitable for Low Ceiling Applications. U.L.507 Listed. 36201/ 36” Commercial Fan Designed for Smaller Areas, Where Minimal Ventilation is Required. Ideally Suited for Isolated Areas and as a Supplemental Cooling Fan. 48201/ 48” Commercial Fan Designed for Commercial Facilities Such as School Classrooms, Offices, Retail Stores, Restaurants. Provides Maximum Area Coverage for Both Summer Cooling and Winter Heat Destratification. 56001LC/ 56” Commercial / School Classroom Fan Designed for Spacious Areas with Low Ceilings Where Larger Blade Diameter Span Creates Maximum Air Velocity and Area Coverage at Lower RPM’s. Engineered Specifically for Continuous Commercial Use With the Same Manufacturing Criteria as Our Heavy Duty Industrial Line. Ideally Suited for Classrooms.

CATALOG NUMBER	BLADE DIA.	VOLTS	MAX. CFM†	AREA COVERAGE PER FAN††	COLOR	SHIP WT. (lbs.)	Price	Add To Cart
36201	36"	120	12,500	1600 sq.ft.	White	20	168.06
48201	48"		21,000	2025 sq.ft.		22	184.60
56001LC	56"		25,500	3025 sq.ft.		24	274.23

Note: Supplied with 8" and 24" downrods.
† Effective amount of air volume moved past a plane 20ft. from fan. All specifications subject to change and improvement.
†† Area coverage rated for heat destratification at 20’ blade mounting height.
Maximum continuous operation ambient temperature 105°F
