PiloTREK WE-200 Radar Level Transmitter
NIVELCO PiloTREK
WE-200 Radar Level Transmitter
|
 |
Nivelco Level Transmitter, Non-Contact, PiloTREK WE-200
Available with Bluetooth® setup, via HART® protocol, up to 98.5" sensing distance, high
temperature units up to 400°F.
|
|
Product Properties
- 2-wire 80 GHz (W-band) radar
- Measuring range up to 98.5 ft
- Accuracy of ±0.08"
- Easy to install due to small antenna diameter
- Plug-in graphic display module
- Horn and plastic encapsulated antennas
- High-temperature version
- Compact design with IP66/IP67 protection
- User-friendly threshold management
- Configuration via Bluetooth® with MobileEView app
- PACTware™ compatible
- NIFLANGE welded stainless steel flange design
- Ex variant
- 5-year warranty
|
Applications
- For measuring the level of liquids, emulsions, and other media
- For large-particle bulk solids
- Storage tanks, chemical tanks, open pits, sumps, wells
- Measurement through a plastic tank roof
- For material prone to vapor formation
- For measuring liquids with a gas blanket
- It can also be used in a vacuum
- Open-channel flow measurement
- Water and wastewater industry
- Energy industry / plant utilities
- Food & beverage
- Chemical & pharmaceutical industry
- Agriculture
- Construction materials
- Heavy industry
- Packaging industry
|
For More information please take a look at the Full:
Bulletin
|
| Supply voltage |
12…36 V DC |
| Ambient temperature |
–40…+158 °F |
| Process temperature |
–40…+400 °F |
| Process pressure |
–14.5…43.5 psi (–0.1…0.3 MPa) |
| Measurement range |
0…98.5 ft |
| Display |
SAP−300 plug-in display |
| Output |
Bluetooth®, 4…20 mA + HART®, SPDT output, service interface |
| Process connection |
1", 1½" BSP / NPT, TriClamp, prepared for welded flange |
| Ingress protection |
IP66 / IP67 |
| Approvals |
ATEX, IECEx, ANATEL, INMETRO |
